Electrical Specifications

Cable Length

5±0.2m 8-Pin

Interface 1

DIN Male 8-Pin

Interface 2

DIN Female

AISG Connector

—

Standard

IEC 60130-9

Environmental Specifications

Temperature Range

−40° to +80° C

Connector Durability

> 500 Cycles

Degree Of Protection

IEC60529, IP67 (Mated Pair)

Electrical Specifications

Withstand Voltage (Continuous)

300 V

Withstand Voltage (Pulse) Test

1000 V / 670 V AC 5A/40°C

Voltage Rated Current

≥ 500 mΩ

Insulation Resistance

≤ 5 MΩ

Contact Resistance

• Power Cores ≥ 0.75 mm²
• Twisted Pair Data Cores ≥ 0.25 mm²

Cable Construction

—
